• Designed for cross cutting mild steel plate, angle iron, rod or pipe, etc..
• Not recommended for non-ferrous metals, wood, glass, concrete or plastic.
• Material must be always clamped to avoid vibration.
• Highly recommended for use with LOW RPM saws only.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number | Teeth Type |
| 0101100 | 100 | 1.6 | 1.2 | 20 | 18 | BT |
| 0101105 | 100 | 1.6 | 1.2 | 20 | 22 | |
| 0101110 | 110 | 1.6 | 1.2 | 20 | 24 | |
| 0101125 | 125 | 1.6 | 1.2 | 20 | 24T | |
| 0101136 | 136 | 1.6 | 1.2 | 20 | 30 | |
| 0101150 | 150 | 1.8 | 1.4 | 20 | 30 | |
| 0101160 | 160 | 1.8 | 1.4 | 20 | 30 | |
| 0101179 | 180 | 1.8 | 1.4 | 20 | 32 | |
| 0101180 | 180 | 1.8 | 1.4 | 20 | 36 | |
| 0101185 | 180 | 1.8 | 1.4 | 20 | 40 | |
| 0101186 | 180 | 1.8 | 1.4 | 20 | 48 | |
| 0101190 | 190 | 1.8 | 1.4 | 20 | 36 | |
| 0101210 | 210 | 1.8 | 1.4 | 25.4 | 48 | |
| 0101216 | 216 | 1.8 | 1.4 | 25.4 | 44 | |
| 0101230 | 230 | 2 | 1.6 | 25.4 | 48 | TCG |
| 0101235 | 235 | 2 | 1.6 | 25.4 | 48 | |
| 0101250 | 250 | 2 | 1.6 | 25.4 | 48 | |
| 0101251 | 250 | 2 | 1.6 | 25.4 | 52 | |
| 0101255 | 250 | 2 | 1.6 | 25.4 | 60 | |
| 0101300 | 305 | 2.4 | 2.0 | 25.4 | 60 | |
| 0101305 | 305 | 2.4 | 2.0 | 25.4 | 80 | |
| 0101349 | 355 | 2.4 | 2.0 | 25.4 | 66 | |
| 0101350 | 355 | 2.4 | 2.0 | 25.4 | 72 | |
| 0101354 | 355 | 2.4 | 2.0 | 25.4 | 80 | |
| 0101400 | 400 | 2.4 | 2.0 | 25.4 | 72 | |
| 0101405 | 400 | 2.8 | 2.4 | 25.4 | 100 |
Different diameters and bore size are available upon request.
• BT and FT teeth are more suitable for various materials, such as mild steel plate, angle iron,
rod or pipe, also can cut wood, plastic, non-ferrous metals etc..
• Start sharp, stay sharp and resist impact damage for long lifetime
| Item NO FT Teeth | Item NO BT Teeth | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| 0103036 | 0103536 | 136 | 1.6 | 1.2 | 20 | 30 |
| 0103060 | 0103560 | 160 | 1.8 | 1.4 | 20 | 30 |
| 0103065 | 0103565 | 165 | 1.8 | 1.4 | 20 | 36 |
| 0103084 | 0103584 | 184 | 2.0 | 1.6 | 20 | 48 |
| 0103021 | 0103621 | 210 | 2.0 | 1.6 | 25.4 | 48 |
| 0103023 | 0103623 | 235 | 2.2 | 1.8 | 25.4 | 48 |
| 0103025 | 0103625 | 254 | 2.2 | 1.8 | 25.4 | 48 |
| 0103030 | 0103730 | 305 | 2.2 | 1.8 | 25.4 | 60 |
| 0103035 | 0103735 | 355 | 2.4 | 2 | 25.4 | 72 |
Different diameters and bore size are available upon request.
• Designed for cross and ripping cutting sandwich panel with polyester inside, also can cut mild steel plate, angle iron, rod or pipe with excellent performance.
• Special cutting carbide teeth provide sharpness and long lifetime.
• Laser-cut blade for anti-vibration, preventing blade warping.
• Highly recommended for use with LOW RPM saws only.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| 0106250 | 250 | 2.2 | 1.8 | 30 | 80 |
| 0106300 | 300 | 2.2 | 1.8 | 30 | 80 |
| 0106305 | 300 | 2.2 | 1.8 | 30 | 96 |
| 0106350 | 350 | 2.4 | 2.0 | 30 | 80 |
| 0106355 | 350 | 2.4 | 2.0 | 30 | 100 |
| 0106400 | 400 | 2.8 | 2.4 | 30 | 100 |
| 0106405 | 400 | 2.8 | 2.4 | 30 | 120 |
| 0106450 | 450 | 3.2 | 2.6 | 30 | 120 |
| 0106500 | 500 | 3.2 | 2.6 | 40 | 120 |
| 0106550 | 550 | 3.6 | 3.0 | 40 | 140 |
| 0106600 | 600 | 3.6 | 3.0 | 40 | 144 |
Different diameters and bore size are available upon request.
• Designed for cross and ripping cutting sandwich panel with mineral wool inside.
• Special cutting carbide teeth provide sharpness and long lifetime.
• Laser-cut blade for anti-vibration, preventing blade warping.
• Highly recommended for use with LOW RPM saws only.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| 01 07 200 | 200 | 2.0 | 1.6 | 30 | 60 |
| 01 07 250 | 250 | 2.2 | 1.8 | 25.4 | 36 |
| 01 07 350 | 350 | 2.6 | 2.0 | 40 | 54 |
| 01 07 400 | 400 | 2.2 | 1.8 | 60 | 64 |
| 01 07 405 | 400 | 3.4 | 2.8 | 70 | 64 |
| 01 07 410 | 400 | 4.0 | 3.2 | 75 | 60 |
| 01 07 450 | 450 | 4.0 | 2.8 | 80 | 84 |
| 01 07 550 | 550 | 4.0 | 3.2 | 70 | 72 |
| 01 07 600 | 600 | 5.5 | 3.5 | 50 | 80 |
Different diameters and bore size are available upon request.
• Suitable for cutting all kinds of aluminum bars, aluminum blocks, brass bars, and other non-ferrous metals, etc..
• TCG teeth with negative hook angle lasts longer than other carbide grades and leaves burr free cuts in all types of non-ferrous metals.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| 0108210 | 210 | 2.4 | 1.8 | 30 | 48 |
| 0108230 | 230 | 2.8 | 2.0 | 30 | 60 |
| 0108250 | 250 | 2.8 | 2.0 | 30 | 60 |
| 0108251 | 250 | 2.8 | 2.0 | 30 | 64 |
| 0108252 | 250 | 2.8 | 2.0 | 30 | 72 |
| 0108305 | 305 | 3.0 | 2.2 | 30 | 72 |
| 0108306 | 305 | 3.0 | 2.2 | 30 | 80 |
| 0108354 | 355 | 3.2 | 2.4 | 30 | 80 |
| 0108355 | 355 | 3.2 | 2.4 | 30 | 84 |
| 0108403 | 405 | 3.2 | 2.4 | 30 | 80 |
| 0108405 | 405 | 3.2 | 2.4 | 30 | 96 |
| 0108450 | 450 | 3.6 | 2.8 | 30 | 100 |
| 0108451 | 450 | 3.6 | 2.8 | 30 | 108 |
| 0108500 | 500 | 4.0 | 3.0 | 30 | 120 |
Different diameters and bore size are available upon request.
• Designed for cutting all kinds of aluminum profiles and other non-ferrous metals, etc..
• Straight sawing by symmetric tooth geometry.
• Very suitable for cutting on thick walled material (>4mm).
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| 0110105 | 105 | 1.8 | 1.1 | 20 | 40 |
| 0110110 | 110 | 1.8 | 1.2 | 22.23 | 36 |
| 0110111 | 110 | 1.8 | 1.2 | 22.23 | 40 |
| 0110125 | 125 | 1.8 | 1.2 | 22.23 | 40 |
| 0110150 | 150 | 2.0 | 1.4 | 30 | 60 |
| 0110180 | 180 | 2.0 | 1.4 | 30 | 54 |
| 0110182 | 180 | 2.0 | 1.4 | 30 | 60 |
| 0110184 | 180 | 2.0 | 1.4 | 30 | 80 |
| 0110200 | 200 | 2.2 | 1.6 | 30 | 60 |
| 0110201 | 200 | 2.2 | 1.6 | 30 | 64 |
| 0110203 | 200 | 2.2 | 1.6 | 30 | 80 |
| 0110210 | 210 | 2.2 | 1.6 | 30 | 60 |
| 0110213 | 210 | 2.2 | 1.6 | 30 | 80 |
| 0110230 | 230 | 2.4 | 1.8 | 30 | 80 |
| 0110235 | 230 | 2.4 | 1.8 | 30 | 100 |
| 0110250 | 250 | 2.4 | 1.8 | 30 | 80 |
| 0110251 | 250 | 2.4 | 1.8 | 30 | 84 |
| 0110254 | 250 | 2.4 | 1.8 | 30 | 100 |
| 0110255 | 250 | 2.4 | 1.8 | 30 | 120 |
| .'0110305 | 305 | 2.8 | 2.0 | 30 | 96 |
| 0110306 | 305 | 2.8 | 2.0 | 30 | 100 |
| 0110310 | 305 | 2.8 | 2.0 | 30 | 120 |
| 0110355 | 355 | 3.0 | 2.2 | 30 | 108 |
| 0110360 | 355 | 3.0 | 2.2 | 30 | 120 |
| 0110405 | 405 | 3.2 | 2.4 | 30 | 120 |
| 0110450 | 450 | 3.2 | 2.4 | 30 | 120 |
| 0110500 | 500 | 4.0 | 3.0 | 30 | 120 |
Different diameters and bore size are available upon request.
• Saw blade suitable for cutting unprocessed chipboard and plywood, also for ripping and cross cutting soft, hard and exotic solid wood.
• Precision and clean cuts, excellent finish and long cutting life.
• Perfect finish by using scoring blades together, especially during cutting laminated materials.
| Item NO | Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| ATB | TCG | |||||
| 0133130 | 0134130 | 130 | 1.8 | 1.2 | 20 | 40 |
| 0133140 | 0134140 | 140 | 1.8 | 1.2 | 20 | 48 |
| 0133160 | 0134160 | 160 | 2.2 | 1.6 | 20 | 48 |
| 0133162 | 0134162 | 160 | 2.2 | 1.6 | 20 | 60 |
| 0133165 | 0134165 | 165 | 2.2 | 1.6 | 30 | 48 |
| 0133180 | 01 34 180 | 180 | 2.4 | 1.6 | 30 | 42 |
| 0133185 | 01 34 185 | 185 | 2.4 | 1.6 | 20 | 48 |
| 0133186 | 01 34 186 | 185 | 2.4 | 1.6 | 20 | 60 |
| 0133190 | 01 34 190 | 190 | 2.6 | 1.8 | 20 | 48 |
| 0133200 | 01 34 200 | 200 | 2.6 | 1.8 | 30 | 48 |
| 0133203 | 01 34 203 | 200 | 2.6 | 1.8 | 30 | 64 |
| 0133210 | 01 34 210 | 210 | 2.8 | 1.8 | 30 | 48 |
| 0133213 | 01 34 213 | 210 | 2.8 | 1.8 | 30 | 64 |
| 0133216 | 01 34 216 | 216 | 2.8 | 1.8 | 30 | 48 |
| 0133235 | 01 34 235 | 235 | 2.8 | 1.8 | 30 | 48 |
| 0133237 | 01 34 237 | 235 | 2.8 | 1.8 | 30 | 64 |
| 0133255 | 01 34 255 | 255 | 3.0 | 2.0 | 30 | 48 |
| 0133256 | 01 34 256 | 255 | 3.0 | 2.0 | 30 | 60 |
| 0133258 | 01 34 258 | 255 | 3.0 | 2.0 | 30 | 80 |
| 0133305 | 01 34 305 | 305 | 3.2 | 2.2 | 30 | 60 |
| 0133307 | 01 34 307 | 305 | 3.2 | 2.2 | 30 | 72 |
| 0133309 | 01 34 309 | 305 | 3.2 | 2.2 | 30 | 96 |
| 0133350 | 01 34 350 | 350 | 3.5 | 2.5 | 30 | 72 |
| 0133355 | 01 34 355 | 350 | 3.5 | 2.5 | 30 | 84 |
| 0133359 | 01 34 359 | 350 | 3.5 | 2.5 | 30 | 96 |
| 0133400 | 01 34 400 | 400 | 4.0 | 2.8 | 30 | 96 |
| 0133450 | 01 34 450 | 450 | 4.2 | 3.0 | 30 | 96 |
| 0133500 | 01 34 500 | 500 | 4.4 | 3.2 | 30 | 108 |
| 0133550 | 01 34 550 | 550 | 4.8 | 3.5 | 30 | 120 |
| 0133600 | 01 34 600 | 600 | 5.4 | 4.0 | 30 | 132 |
Different diameters and bore size are available upon request.
• Designed for continuously cutting wood, chipboard, single or double-sided laminated panels, MDF and plywood, up to 30mm cutting height.
• Precision and clean cuts, excellent finish and long cutting life.
• Perfect finish by using scoring blades together, especially during cutting laminated materials.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number | Teeth Type |
| 01 31 200 | 200 | 3.2 | 2.2 | 30 | 64 | TCG 5º |
| 01 31 220 | 220 | 3.2 | 2.2 | 30 | 64 | TCG 5º |
| 01 31 250 | 250 | 3.2 | 2.2 | 30 | 60 | TCG 5º |
| 01 31 253 | 250 | 3.2 | 2.2 | 30 | 80 | TCG 5º |
| 01 31 300 | 300 | 3.2 | 2.2 | 30 | 72 | TCG 5º |
| 01 31 305 | 300 | 3.2 | 2.2 | 30 | 84 | TCG 5º |
| 01 31 310 | 300 | 3.2 | 2.2 | 30 | 96 | TCG 5º |
| 01 31 350 | 350 | 3.5 | 2.5 | 30 | 72 | TCG 5º |
| 01 31 355 | 350 | 3.5 | 2.5 | 30 | 108 | TCG 5º |
| 01 31 358 | 350 | 3.5 | 2.5 | 30 | 120 | TCG 5º |
Different diameters and bore size are available upon request.
•Designed for continuously cutting wood, chipboard, single or double-sided laminated panels, MDF and plywood, up to 40mm cutting height.
• TCG teeth with negative hook angle lasts longer than other carbide grades and leaves burr free cuts in all types of chipboards, MDF, etc..
• Not using scoring blades together.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number | Teeth Type |
| 01 32 220 | 220 | 3.2 | 2.2 | 30 | 56 | TCG -5º |
| 01 32 221 | 220 | 3.2 | 2.2 | 30 | 64 | TCG -5º |
| 01 32 250 | 250 | 3.2 | 2.2 | 30 | 60 | TCG -5º |
| 01 32 253 | 250 | 3.2 | 2.2 | 30 | 80 | TCG -5º |
| 01 32 300 | 300 | 3.2 | 2.2 | 30 | 72 | TCG -5º |
| 01 32 305 | 300 | 3.2 | 2.2 | 30 | 96 | TCG -5º |
| 01 32 350 | 350 | 3.5 | 2.5 | 30 | 84 | TCG -5º |
| 01 32 353 | 350 | 3.5 | 2.5 | 30 | 108 | TCG -5º |
| 01 32 355 | 350 | 3.5 | 2.5 | 30 | 120 | TCG -5º |
Different diameters and bore size are available upon request.
• Designed for scoring groove on coated wood based materials, to avoid tearing out on the bottom.
• Optimum scoring depth is 1.0-2.5mm.
• The cutting width of scoring saw blade must be the same as that of the main saw blade.
• The size of the groove is obtained by adjusting the height of the scoring saw blade.
• Increasing the height of scoring saw blade increases the size of the groove.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number | Teeth Type |
| 01 38 005 | 100 | 3.1-4.3 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 010 | 110 | 3.1-4.3 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 015 | 115 | 3.1-4.3 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 016 | 115 | 4.1~5.2 | 2.8 | 20 | 24 | ATB 0° |
| 01 38 020 | 120 | 2.8-4.0 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 021 | 120 | 3.1-4.3 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 022 | 120 | 3.4-4.6 | 2.5 | 20 | 24 | ATB 0° |
| 01 38 025 | 125 | 3.1-4.3 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 026 | 125 | 3.1-4.3 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 027 | 125 | 3.4-4.6 | 2.2 | 20 | 24 | ATB 0° |
| 01 38 040 | 150 | 3.1-4.3 | 2.2 | 30 | 36 | ATB 8º |
| 01 38 041 | 150 | 4.3-5.6 | 3.2 | 30 | 36 | ATB 8º |
| 01 38 045 | 160 | 3.1-4.3 | 2.2 | 20 | 36 | ATB 8º |
| 01 38 046 | 160 | 4.3-5.5 | 3.2 | 25.4 | 36 | ATB 8º |
| 01 38 047 | 160 | 4.5-5.7 | 3 | 45 | 36 | ATB 8º |
| 01 38 060 | 180 | 3.1-4.3 | 2.2 | 25.4 | 42 | ATB 8º |
| 01 38 061 | 180 | 4.3-5.5 | 3.2 | 30 | 36 | ATB 8º |
| 01 38 070 | 200 | 4.3-5.5 | 3.2 | 30 | 36 | ATB 8º |
Different diameters and bore sizes are available upon your request.
• Adjustable scoring saw blade for scoring groove on coated wood based materials, to avoid tearing out on the bottom.
• Adjustable cutting width with spacers or rapid system, to suit the kerf of the main saw blade.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number | Teeth Type |
| 01 39 003 | 100 | 2.8-3.6 | / | 20 | 12+12 | ATB 5° |
| 01 39 005 | 120 | 2.8~3.6 | / | 20 | 12+12 | ATB 5° |
| 01 39 006 | 120 | 4.0~5.0 | / | 50 | 12+12 | ATB 5° |
| 01 39 010 | 125 | 2.8~3.6 | / | 20 | 12+12 | ATB 5° |
| 01 39 012 | 125 | 2.8~3.6 | / | 20 | 14+14 | ATB 5° |
| 01 39 013 | 125 | 4.0~4.7 | / | 20 | 20+20 | ATB 5° |
| 01 39 014 | 125 | 4.0-5.0 | / | 45 | 12+12 | ATB 5° |
| 01 39 020 | 200 | 4.0~5.2 | / | 50 | 28+28 | ATB 5° |
Different diameters and bore sizes are available upon your request.
• Suitable for ripping cut.
• Thin kerf to increase saw blade performance, provide faster cuts and less waste.
• Anti-kick back reduces vibration.
| Item NO | Diameter | Kerf | Plate-Thickness | Bore | Teeth Number |
| 01 11 250 | 250 | 2.5 | 1.6 | 30 | 24 |
| 01 11 300 | 300 | 2.6 | 1.8 | 30 | 28 |
| 01 11 350 | 350 | 3.0 | 2.2 | 30 | 32 |
Different diameters and bore size are available upon request.
Copyright © OXCRAFT
Zhenjiang Tisen Tools Co., Ltd 2024, All rights reserved.
Copyright © OXCRAFT
Zhenjiang Tisen Tools Co., Ltd 2024, All rights reserved.
