DIAMOND TOOLS

Porcelain Saw Blade

ULTRATHIN MESHY SAW BLADE

•Hot press sintered.

•Designed for straight dry cutting microlite tile, porcelain, ceramic, tile, etc..

•Ultrathin cutting edge for less chip.

•Meshy segment for more powerful dry cutting performance.

ITEM NO.	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO.	Inch	mm	mm	mm	mm
0201010	4-1/3''	110	20	1.2	10
0201015	4-1/2''	115	22.23	1.2	10
0201020	5''	125	22.23	1.2	10
0201030	7''	180	25.4	1.8	10
0201035	8''	200	25.4	1.8	10
0201040	9''	230	25.4	2.0	10
0201048	12“	300	32.0	2.2	10

Different bore size is available upon your request.

Porcelain Saw Blade

ULTRATHIN TURBO SAW BLADE

•Hot press sintered.

•Designed for straight dry cutting porcelain, ceramic, tile, etc..

•Ultrathin cutting edge for less chip.

ITEM NO. without flange	ITEM NO. with flange	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO. without flange	ITEM NO. with flange	Inch	mm	mm	mm	mm
0202009	0202109	4 1/3“	110	20	1.2	8
0202010	0202110	4-1/3	110	20	1.4	8
0202015	0202115	4-1/2	115	22.23	1.3	7.5
0202020	0202120	5	125	22.23	1.4	7.5
0202025	0202125	6	150	22.23	1.5	7.5
0202030	0202130	7	180	25.4	1.7	7.5
0202040	0202140	9	230	25.4	1.9	7.5

Different bore size is available upon your request.

Porcelain Saw Blade

ULTRATHIN V-TYPE SAW BLADE

•Hot press sintered.

•Designed for straight dry cutting porcelain, ceramic, tile, etc..

•Ultrathin cutting edge for less chip.

•V-type segment for more powerful dry cutting performance.

ITEM NO. without flange	ITEM NO. with flange	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO. without flange	ITEM NO. with flange	Inch	mm	mm	mm	mm
0201605	0201655	4 1/8”	105	20	1.4	8
0201610	0201660	4-1/3''	110	20	1.4	8
0201620	0201670	5''	125	22.23	1.4	8

Different bore size is available upon your request.

Porcelain Saw Blade

ULTRATHIN RIM SAW BLADE

•Hot press sintered.

•Designed for straight dry cutting porcelain, ceramic, tile, etc..

•Ultrathin cutting edge for less chip.

ITEM NO.	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO.	Inch	mm	mm	mm	mm
0203615	4-1/2''	115	22.23	/	8
0203620	5“	125	22.23	/	8

Different bore size is available upon your request.

Porcelain Saw Blade

SOCCE SHAPE SAW BLADE

•Hot press sintered.

•Designed for dry&wet straight cutting and grinding porcelain, ceramic, tile, etc..

ITEM NO. soccer meshy	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO. soccer meshy	Inch	mm	mm	mm	mm
0202515	4-1/2''	115	22.23	/	25
0202520	5''	125	22.23	/	25

Different bore size is available upon your request.

Porcelain Saw Blade

ULTRATHIN SUPER-WIDE SEGMENT SAW BLADE

•Hot press sintered.

•Designed for wet cutting microlite tile, porcelain, ceramic, tile, etc..

•Ultrathin cutting edge for chip free cutting.

•Super-wide segment for long lifetime.

ITEM NO.	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO.	Inch	mm	mm	mm	mm
0203030	7"	180	25.4	/	25
0203035	8"	200	25.4	/	25
0203040	9"	230	25.4	/	25
0203045	10"	250	25.4	/	25

Different bore size is available upon your request.

Porcelain Saw Blade

ULTRATHIN RIM SAW BLADE-GEN

•Hot press sintered.

•Designed for straight wet cutting porcelain, ceramic, tile, etc..

•Ultrathin cutting edge for less chip.

ITEM NO. 8mm	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO. 8mm	Inch	mm	mm	mm	mm
0203309	4-1/3''	110	20	/	8
0203314	4-1/2''	115	22.23	/	8
0203319	5''	125	22.23	/	8
0203330	7''	180	25.4	/	8
0203335	8''	200	25.4	/	8
0203340	9''	230	25.4	/	8
0203345	10''	250	25.4	/	8
0203350	12''	300	25.4	/	8

Different bore size is available upon your request.

Concrete Saw Blade

TURBO SEGMENTED SAW BLADE WITH MULTIHOLE

•Hot press sintered.

•Suitable for straight dry cutting concrete.

•Super wide segment for long lifetime.

ITEM NO.	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO.	Inch	mm	mm	mm	mm
0204015	4-1/2"	115	22.23	2.0	12
0204020	5"	125	22.23	2.2	12
0204030	7"	180	22.23	2.4	12
0204040	9''	230	22.23	2.6	12
0204045	10"	250	25.4	3	12
0204050	12"	300	25.4	3.2	12
0204055	14"	350	25.4	3.4	13

Different arbor size is available upon your request.

Concrete Saw Blade

TURBO SAW BLADE

•Hot press sintered.

•Suitable for straight dry cutting reinforced concrete with small rebar, concrete with hard filler and concrete without hard filler.

ITEM NO. 7mm	ITEM NO. 10mm	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO. 7mm	ITEM NO. 10mm	Inch	mm	mm	mm	mm
0204110	0204111	4-1/3"	110	20	2.0	10
0204115	0204116	4-1/2"	115	22.23	2.2	10
0204120	0204121	5"	125	22.23	2.4	10
0204130	0204131	7"	180	22.23	2.6	10
0204135	0204136	8"	200	22.23	2.6	10
0204140	0204141	9"	230	22.23	2.8	10
0204145	0204146	10"	250	25.4	3.0	10
0204150	0204151	12"	300	25.4	3.2	10

Different arbor size is available upon your request.

Stone Saw Blade

SEGMENTED SAW BLADE

• Hot press sintered.

• Suitable for straight dry cutting of granite,marble, quartzite, limestone, sand stone, quartz shale and sand-cement mix.

ITEM NO. 7mm	ITEM NO. 10mm	Outer Diameter		Bore	Seg. Thickness
ITEM NO. 7mm	ITEM NO. 10mm	Inch	mm	mm	mm
0205105	0205106	4''	105	20	1.6
0205110	0205111	4-1/3''	110	20	1.7
0205115	0205116	4-1/2''	115	22.23	1.8
0205120	0205121	5''	125	22.23	2.0
0205125	0205126	6''	150	22.23	2.2
0205130	0205131	7''	180	22.23	2.4
0205135	0205136	8''	200	22.23	2.6
0205140	0205141	9''	230	22.23	2.6
0205145	0205146	10''	250	25.4	2.8
0205150	0205151	12''	300	25.4	2.8
0205155	0205156	14''	350	25.4	3

Different arbor size is available upon your request.

Stone Saw Blade

TURBO SAW BLADE

• Hot press sintered.

• Suitable for straight dry cutting of granite, marble, limestone and ceramic tile.

ITEM NO. 7mm	ITEM NO. 10mm	Outer Diameter		Bore	Seg. Thickness
ITEM NO. 7mm	ITEM NO. 10mm	Inch	mm	mm	mm
0205205	0205206	4''	105	20	1.8
0205210	0205211	4-1/3''	110	20	2.0
0205215	0205216	4-1/2''	115	22.23	2.2
0205220	0205221	5''	125	22.23	2.4
0205225	0205226	6''	150	22.23	2.5
0205230	0205231	7''	180	22.23	2.6
0205235	0205236	8''	200	22.23	2.6
0205240	0205241	9''	230	22.23	2.8
0205245	0205246	10''	250	25.4	3.0
0205250	0205251	12''	300	25.4	3.2

Different arbor size is available upon your request.

General Purpose Saw Blade

Segmented Saw Blade

• Hot press sintered.

• Suitable for straight dry cutting of a variety of building materials, recommended for cutting hard, dense material, hard granite and hard concrete.

ITEM NO. 7mm	ITEM NO. 10mm	Outer Diameter		Bore	Seg. Thickness	Seg. Height
ITEM NO. 7mm	ITEM NO. 10mm	Inch	mm	mm	mm	mm
0206010	0206011	4-1/3''	110	20	2.0	7/10
0206015	0206016	4-1/2''	115	22.23	2.2	7/10
0206020	0206021	5''	125	22.23	2.4	7/10
0206025	0206026	6''	150	22.23	2.5	7/10
0206030	0206031	7''	180	22.23	2.6	7/10
0206035	0206036	8''	200	22.23	2.6	7/10
0206040	0206041	9''	230	22.23	2.8	7/10
0206045	0206046	10''	250	25.4	3.0	7/10
0206050	0206051	12''	300	25.4	3.2	7/10

Different arbor size is available upon your request.
